- Technology, design and production “Made in Italy”
- Reduced dimensions (only 780 mm depth)
- Ideal for placement in any location
- Low energy consumption and low enviromental impact
- White prepainted sheet metal tank (suitable for food contact) with high-pressure injected CFCs-free polyurethane insulation (density 40 Kg / m³)
- With straight tempered glass (VD)
- Front glass opening
- Built-in unit (CG)
- Gas R290
- Not multiplexable
- Easy installation, ready to use
VIGO
78
tradurre.
Suitable for
Meat
Gastronomy
Dairy products
Cured meats
Snack
PDF data sheet
tradurre
GENERAL FEATURES
Standard set-up
Thermoformed and insulated side walls (thickness 40 mm each).
Tempered side glass pre-arranged for intermediate shelf.
Electronic control panel.
Refrigerated storage with doors.
Led ceiling light.
Tempered glass intermediate shelf with supports;
Stainless steel working top with base channel to fit rear plexiglass sliding doors (optional).
Stainless steel display surface.
Automatic water evaporation system.
Off-cycle defrosting.
Standard packaging: pallet + nylon (wooden crate on request).
Available accessories
Rear plexiglass sliding doors;
Kit of no. 4 castors.
TECHNICAL FEATURES
R290
R290
Typology of refrigeration
Semi-ventilated (SV)
Available sizes
LENGHTS mm:
DEPTH 780 mm
100
L 1040150
L 1520200
L 2000250
L 2480300
L 2960DEPTH 780 mm
Operating temperature
+ 2°C
+ 5°C
- Testing data: temperature + 25°C / relative humidity 60%
Standard RAL colours
FRONT PANEL
1018
3020
5013
6026
9005
1028
2008
5024
6019
9010
STANDARD SIDE WALLS
WHITE
GREY
BLACK
